HF-430E-790
Oval-shaped Cutting Knife Chrysanthemum Eye Machine

2.5 cm extended oval daisy-eye buttonhole

1.7 cm oval daisy-eye buttonhole

Oval daisy-eye buttonhole for casual trousers

Oval daisy-eye buttonhole—knit fabric dedicated

Oval daisy-eye buttonhole for knits with backing-strip interlining

Oval daisy-eye buttonhole machine (retro-fitted for webbing-end cutting)

Product advantages

1.High-quality imported spare parts are selected (featuring low noise, durability, and product value retention)

2.The machine adopts a large connecting rod gear box oil-sealed structure (for wear resistance)

3.A touchscreen programming system is used, allowing adjustment of the pattern shape, length.and stitch count

4.The front and rear bar-tacking pattems are elliptical, which is more aesthetically pleasing than the traditional straight eyelets

5.With cutter function: it can cut fabric continuously according to the sewing length of the eyelet

6.lt supports three working modes: cut first then sew, sew first then cut, or sew the bobbin thread first + cut with the cutter + embroider the eyelet afterwards

7.Two oval size specifications (A: 17mm/ B: 25mm) are available as options


Application field

Hoodie hood eyelets、Casual pants drawstring eyelets




Specifications
ModelHF-430E-790-17HF-430E-790-25
Rotational Speed32003200
Machine NeedleDPX5 11-16#DPX5 11-16#
Lightweight Material
Medium-weight Material
Heavyweight Material
Thread Trimming
Packaging Dimensions695x435x535mm695x435x535mm
Weight70/75kg90/95kg
