A:SEWINGMACHINEHEAD

1.The machine head adopts imported high-quality spare parts (featuring low noise, durability, and product value retention)

2.The machine adopts a oil-sealed structure for the large connecting rod gear box (excelent wear resistance)

3.Equipped with the most stable computer control system (programmable)

4.Standard sewing width for elastic: 55mm (optional: 60mm/80mm/100mm)

5.The machine head is standardly equipped with Haifa large shuttle 1906AS (optional: Juki/Brother/pattern sewing machine)

6.Rubber band circumference: minimum 17cm (15cm available on custom order); maximum unlimited

B:AUTOMATEDEQUIPMENT

1.Adopt a PLC control system (more stable, higher efficiency, and easier maintenance)

2.Select SMC components (more stable and better value retention)

3.Choose imported electronic components (more durable and zero rubber band error)

4.Use a stepper motor for belt feeding (high speed)

A:STANDARDFEATURES

1.Elastic Material Loosening Function

2.Heating Pre-shrinking Setting Function

3.Real-time Feeding Sensing Function

4.Letter Logo Positioning Function

5.Elastic Length Deviation Detection Function

6.Elastic Joint Detection Function  (and exclude the connector)

7.Cold knife for material cutting function

8.Anti-overlapping Stitching Function

9.Digital Material Co lecting Function (Size Differentiation)

B:OPTIONALFEATURES

1.Marking Point Function

2.Pad Printing and Coding Function (marking sizes: M, L. XL, XXL)

3.Color Mark Industrial Camera (for distinguishing same-color elastic bands and same-color letters)

4.Cold knife for material cutting function

Elastic tendons loosening function

Heating pre-shrink shaping function

Locate the letter LOGO

For color scale industrial camera

Elastic joint detection function

Code function

Draw line point function

Cutting function (ultrasonic)

Cutting function (cold knife)

Automatic feeding function

Anti-overlap seam function

Digital receiving function (distinguish size code)

Super large LCD screen (interchangeable in English and Chinese)

Pneumatic Presser Foot(Higher Efficiency)

Pneumatic Cylinder MaterialFeeding(Faster Sewing Speed)

Imported large swing shuttle and imported large bobbin case(large bobbin winding capacity)

Computer touch screen, easy to edit and change patterns

Imported SMC
